Omron OMNUC G Series User Manual

4-46
4-3 Wiring Conforming to EMC Directives
System Design
4
Conformity to IEC 61800-5-1
 Ground fault protection
G-series servo drive do not have ground fault protection function. Install a circuit breaker (MCCB)
or a leakage circuit breaker (ELCB) in the wiring, according to the grounding system.
The conditions for ground fault protection by the cercuit breakers are as follows: The requirements
of EN 60364-4-41 are met under these conditions.
For TT systems, please comply with the local laws and regulations of the country or region where
the servo system is installed and used. The rated sensitivity current and loop impedance of the earth
leakage breaker are specified in some cases. The type B ELCB may be specified.
For TN system
Model
MCCB
Voltage
to earth
[V]
Acceptable
maximum fault
loop impedance
[Ω]
Rated current
[A]
Type name Manufacturer
R88D-G*A5L* 10 BW50RAGU Fuji Electric 100 0.28
R88D-G*01L*
10
BW50RAGU
Fuji Electric 100 0.28
R88D-G*01H*
10
BW50RAGU
Fuji Electric 200 0.84
R88D-G*02H*
10
BW50RAGU
Fuji Electric 200 0.84
R88D-G*02L*
10 BW50RAGU Fuji Electric 100 0.29
R88D-G*04H*
10
BW50RAGU
Fuji Electric 200 0.84
R88D-G*04L* 10
BW50RAGU
Fuji Electric 100 0.45
R88D-G*08H* 15
BW50RAGU
Fuji Electric 115 0.38
R88D-G*10H* 20 BW50RAGU Fuji Electric 115 0.26
R88D-G*15H* 20
BW50RAGU
Fuji Electric 115 0.28
R88D-G*20H* 30
BW50RAGU
Fuji Electric 115 0.23
R88D-G*30H* 50
BW50RAGU
Fuji Electric 115 0.17
R88D-G*50H* 50 BW50RAGU Fuji Electric 115 0.17
