3-71
3-4 Cable and Connector Specifications
3
Specifications
Brake Cables
: 003 to 050
Moving Bend Test
*1. Encoder cable: 30 to 50 m only
Stroke: 550 mm, 50 times/min
Model Minimum bending radius (R)
R88A-CAGABR 45 mm
Stroke:
750 mm
Bending
radius (R)
30 times/min
