Omron OMNUC G Series User Manual

3-88
3-8 MECHATROLINK-II Repeater Specifications
3
Specifications
Connection Method
The following diagram shows an example of connections between a host Controller, Servo Drives,
and a Repeater.
MECHATROLINK-II
MECHATROLINK-II
30 m or less: 15 nodes max.
30 to 50 m: 14 nodes max.
100 m max.: Maximum number of nodes connectable to Controller
(16 nodes max. for CJ1W/CS1W-NCF71)
30 m or less: 16 nodes max.
30 to 50 m: 15 nodes max.
