Omron OMNUC G Series User Manual

4-19
4-2 Wiring
System Design
4
 R88D-GN08H-ML2/-GN10H-ML2/-GN15H-ML2
RT
NFB
S
123
456
E
NF
1MC
PL
L1C
L2C
L1
L2
L3
ALMCOM
/ALM15
16
CN1
X
BKIR
BKIRCOM
XB
W
V
U
B
E
M
CN2
(*3)
(*2)
CN1
CN1
B1
B3
B2
(*4)
CNB
CNB
CNA
CNA
X
XB
1MC
X
*1. Recommended products are
listed in 4-3 Wiring Conforming
to EMC Directives.
*2.
*3.
*4.
Connect B2-B3 for the models
with a built-in regeneration resistor
(GN08H-ML2 to GN15H-ML2).
If the amount of regeneration is large,
disconnect B2-B3 and connect an
External Regeneration Resistor to B1-B2.
Recommended relay: MY Relay
(24 V), by OMRON. For example,
the MY2 Relay's rated inductive
load is 2 A at 24 VDC and applicable to
all G-Series Servomotors with brakes.
The brake is not affected by the
polarity of the power supply.
Regeneration
resistor
Servo error display
User
control
device
Control Cable
Encoder Cable
Noise filter
(*1)
(Ground to
100 Ω or less.)
Main-circuit contactor (*1)
Three-phase 200 to 240 VAC, 50/60 Hz
24 VDC
(Ground to
100 Ω or less.)
OMNUC G-Series
AC Servomotor
OMNUC G-Series
AC Servo Drive
Power Cable
Reactor
24 VDC
24 VDC
1MC
OFF
ON
X
Surge suppressor (*1)
Main circuit power supply
