2-18
2-1 Standard Models
2
Standard Models and Dimensions
Note There are separate connectors for power and brakes for 3,000-r/min Servomotors of 50 to
750 W, Flat Servomotors, and Servomotors of 6 kW or higher.
Therefore, when a Servomotor with a brake is used, it will require both a Power Cable for a
Servomotor without a brake and a Brake Cable.
Specifications
Model
For Servomotor without
brake
For Servomotor with
brake
1,500-r/min Servomotors of 7.5 kW,
1,000-r/min Servomotors of 6 kW
3 m R88A-CAGE003S ---
5 m R88A-CAGE005S ---
10 m R88A-CAGE010S ---
15 m R88A-CAGE015S ---
20 m R88A-CAGE020S ---
30 m R88A-CAGE030S ---
40 m R88A-CAGE040S ---
50 m R88A-CAGE050S ---
