2-1 Standard Models
2
Standard Models and Dimensions
 Connectors
 Control Cables
 External Regeneration Resistors
 Reactors
Specifications Model
Servomotor Connector for Encoder
Cable
Absolute Encoder R88A-CNG01R
Incremental Encoder R88A-CNG02R
Control I/O Connector (CN1) R88A-CNU01C
Encoder Connector (CN2) R88A-CNW01R
Power Cable Connector (750 W max.) R88A-CNG01A
Brake Cable Connector (750 W max.) R88A-CNG01B
Specifications Model
Connector Terminal Block Cables
1 m XW2Z-100J-B33
2 m XW2Z-200J-B33
Connector Terminal Block
M3 screw type XW2B-20G4
M3.5 screw type XW2B-20G5
M3 screw type XW2D-20G6
Specifications Model
Regeneration capacity: 20 W, 50  (with 150
C thermal switch) R88A-RR08050S
Regeneration capacity: 20 W, 100  (with 150
C thermal switch) R88A-RR080100S
Regeneration capacity: 70 W, 47  (with 170
C thermal switch) R88A-RR22047S1
Regeneration capacity: 180 W, 20  (with 200
C thermal switch) R88A-RR50020S
Specifications Model
R88D-GNA5L-ML2/-GN01H-ML2 3G3AX-DL2002
R88D-GN01L-ML2/-GN02H-ML2 3G3AX-DL2004
R88D-GN02L-ML2/-GN04H-ML2 3G3AX-DL2007
R88D-GN04L-ML2/-GN08H-ML2/-GN10H-ML2 3G3AX-DL2015
R88D-GN15H-ML2 3G3AX-DL2022
R88D-GN08H-ML2/-GN10H-ML2/-GN15H-ML2 3G3AX-AL2025
R88D-GN20H-ML2/-GN30H-ML2 3G3AX-AL2055
R88D-GN50H-ML2 3G3AX-AL2110
R88D-GN75H-ML2 3G3AX-AL2220
