2-2 External and Mounting Hole Dimensions
2
Standard Models and Dimensions
 Three-phase 200 VAC: R88D-GN30H-ML2/-GN50H-ML2 (2 to 5 kW)
Wall Mounting
External Dimensions
Mounting Hole Dimensions
5.25.2
10015
65
5.2
R2.6
R2.6
R2.6 R2.6
5.2 dia.
5.2 dia.
5.2
200
250 240 220
130
10015
65
70
3.5
3.5
0
G
IM
SP
COM
X10
3
2
1
ADR
AC SERVO DRIVER
X1
6
7
8
9
0
1
2
3
4
5
Six, M4
130
220
15
240
100
50
