2-2 External and Mounting Hole Dimensions
2
Standard Models and Dimensions
3,000-r/min Flat Servomotors
2
,000-r/min Servomotors
Motor model 1/5 1/11 1/21 1/33 1/45
R88M-
GP10030

R88G-
HPG11B05100PB

R88G-
HPG14A11100PB

R88G-
HPG14A21100PB

R88G-
HPG20A33100PB

R88G-
HPG20A45100PB

R88M-
GP20030

R88G-
HPG14A05200PB

R88G-
HPG20A11200PB

R88G-
HPG20A21200PB

R88G-
HPG20A33200PB

R88G-
HPG20A45200PB

R88M-
GP40030

R88G-
HPG20A05400PB

R88G-
HPG20A11400PB

R88G-
HPG20A21400PB

R88G-
HPG32A33400PB

R88G-
HPG32A45400PB

Motor model 1/5
1/11
(1/12 for flange size
No.65)
1/21
(1/20 for flange size
No.65)
1/33
(1/25 for flange size
No.65)
1/45
R88M-
G1K020T
R88G-
HPG32A053K0B

(Also used with
R88M-G3K030T)
R88G-
HPG32A112K0SB

(Also used with
R88M-G2K020T)
R88G-
HPG32A211K0SB
R88G-
HPG50A332K0SB

(Also used with
R88M-G2K020T)
R88G-
HPG50A451K0SB
R88M-
G1K520T
R88G-
HPG32A053K0B
(Also used with
R88M-G3K030T)
R88G-
HPG32A112K0SB

(Also used with
R88M-G2K020T)
R88G-
HPG50A213K0B

(Also used with
R88M-G3K030T)
R88G-
HPG50A332K0SB

(Also used with
R88M-G2K020T)
---
R88M-
G2K020T
R88G-
HPG32A053K0B

(Also used with
R88M-G3K030T)
R88G-
HPG32A112K0SB
R88G-
HPG50A213K0B

(Also used with
R88M-G3K030T)
R88G-
HPG50A332K0SB
---
R88M-
G3K020T
R88G-
HPG32A054K0B
(Also used with
R88M-G4K030T)
R88G-
HPG50A115K0B

(Also used with
R88M-G5K030T)
R88G-
HPG50A213K0SB
R88G-
HPG65A253K0SB

---
R88M-
G4K020T
R88G-
HPG50A054K0SB

R88G-
HPG50A114K0SB

R88G-
HPG65A204K0SB

R88G-
HPG65A254K0SB

---
R88M-
G5K020T
R88G-
HPG50A055K0SB

R88G-
HPG50A115K0SB

R88G-
HPG65A205K0SB

R88G-
HPG65A255K0SB

---
R88M-
G7K515T
R88G-
HPG65A057K5SB

R88G-
HPG65A127K5SB

--- --- ---
