Servicing the Service Processor Card 109
Servicing the Service Processor Card
The service processor card is a cold-service component that can be replaced only after you have
removed the main module. For the location of the service processor card, see “Main Module
Internal Component Locations” on page 17.
Caution - This procedure requires that you handle components that are sensitive to electrostatic
discharge. This discharge can cause server components to fail.
These topics describe how to service the service processor card.
Steps Description Links
1. Determine if the service processor card is faulty. “Determine if the Service Processor Card Is
Faulty” on page 109
2. Remove the main module so that you can replace the
service processor card.
“Remove the Main Module” on page 91
3. Replace the service processor card. ■ “Remove the Service Processor
Card” on page 110
■ “Install the Service Processor
Card” on page 112
4. Install the main module after you have replaced the
service processor card.
“Install the Main Module” on page 95
5. Verify the replacement. “Verify the Service Processor
Card” on page 114
Related Information
■
“Identifying Components”
■
“Detecting and Managing Faults”
■
“Preparing for Service”
■
“Component Service Task Reference” on page 23
■
“Returning the Server to Operation”
Determine if the Service Processor Card Is Faulty
When a fault occurs with the service processor card, the following LEDs are lit:
