Main Module Internal Component Locations
Identifying Components 17
This figure shows a processor module with all of the DIMM slots populated with DIMMs.
All of the DIMM slots must be populated with the same type of DIMMs. For guidelines, see
“DIMM Configuration” on page 71.
No. Description Link
1 DIMMs “Servicing DIMMs”
Main Module Internal Component Locations
These components are accessible after you remove the main module from the front of the
server.
