Front Panel Components (Service)
14 SPARC T5-8 Server Service Manual • November 2015
Front Panel Components (Service)
No. Description Links
1 Hard drives (8) “Servicing Hard Drives”
“Supported Storage Devices” on page 18
2 Processor modules (0 to 3, bottom to top) or
processor filler modules (slot 1 and slot 2)
“Servicing Processor Modules”
“Server Upgrade Process” on page 59
3 Main module “Servicing the Main Module”
4 Power supplies (0 to 3, left to right) “Servicing Power Supplies”
Related Information
■
“Rear Panel Components (Service)” on page 15
