Install a PCIe Card
Servicing PCIe Cards 165
Related Information
■
“Install a PCIe Card” on page 165
■
“Install a Card Carrier” on page 168
Install a PCIe Card
Caution - This procedure involves handling circuit boards that are extremely sensitive to static
electricity. Ensure that you follow ESD preventative practices to avoid damaging the circuit
boards. See “Prevent ESD Damage” on page 57.
1.
Determine your first step:
a.
If you are installing a new card and need an empty carrier, see “Remove a
Card Carrier” on page 155.
b.
If you are replacing a faulty card and have already removed its carrier from
the server, go to Step 3.
2.
Unlatch and swing open the top of the PCIe card carrier.
3.
Remove the PCIe card from its packaging.
