Servicing the Rear I/O Module 173
Servicing the Rear I/O Module
The rear I/O module is a cold-service component that can be replaced only after you have
removed all of the power from the server. For the location of the PCIe cards, see “Rear I/O
Module Port Locations” on page 21.
Caution - This procedure requires that you handle components that are sensitive to electrostatic
discharge. This discharge can cause server components to fail.
These topics describe service procedures for the rear I/O module in the server.
Steps Description Links
1. Determine if the rear I/O module is faulty. “Determine if the Rear I/O Module Is
Faulty” on page 173
2. Replace the rear I/O module. ■ “Remove the Rear I/O Module” on page 174
■ “Install the Rear I/O Module” on page 176
3. Verify the replacement. “Verify the Rear I/O Module” on page 178
Related Information
■
“Identifying Components”
■
“Detecting and Managing Faults”
■
“Preparing for Service”
■
“Component Service Task Reference” on page 23
■
“Returning the Server to Operation”
Determine if the Rear I/O Module Is Faulty
1.
Log in to Oracle ILOM.
See “Log In to Oracle ILOM (Service)” on page 28.
2.
Start the faultmgmt shell.
-> start SP/faultmgmt/shell
