Processor Module LEDs
Servicing Processor Modules 61
Related Information
■
“Remove a DIMM or DIMM Filler Panel” on page 76
■
“Install a DIMM” on page 78
■
“Check for Faults” on page 41
■
“Removing Power From the Server” on page 53
■
“Remove a Processor Module or Processor Filler Module” on page 63
■
“Install a Processor Module or Processor Filler Module” on page 67
■
“Returning the Server to Operation”
■
“Root Complex Connections (Four Processor Modules)” on page 150
■
“PCIe Card Installation Guidelines” on page 153
Processor Module LEDs
No. LED Icon Description
1 Ready to Remove (blue) Indicates that a processor module can be
removed.
2 Service Required (amber) Indicates that the processor module has
experienced a fault condition.
3 OK (green) Indicates if the processor module is available for
use.
■ On – The server is running and the processor
module is powered up.
