Hard Drive LEDs
82 SPARC T5-8 Server Service Manual • November 2015
■
“Component Service Task Reference” on page 23
■
“Returning the Server to Operation”
Hard Drive LEDs
No. LED Icon Description
1 Ready to Remove
(blue)
Indicates that a drive can be removed during a hot-service
operation.
2 Service Required
(amber)
Indicates the drive's availability for use.
■ On – Read or write activity is in progress.
■ Off – Drive is idle and available for use.
3 Okay OK Indicates normal operation. Blinking indicates that the drive is
in use.
Related Information
■
“Determine Which Hard Drive Is Faulty” on page 82
■
“Remove a Hard Drive” on page 83
Determine Which Hard Drive Is Faulty
The following LEDs are lit when a hard drive fault is detected:
■
System Service Required LEDs on the front panel and rear I/O module
■
Service Required LED on the faulty drive
