Chassis Subassembly Components
22 SPARC T5-8 Server Service Manual • November 2015
Chassis Subassembly Components
No. Description Links
1 Hard drives (8) “Servicing Hard Drives”
2 Front I/O assembly “Servicing the Front I/O Assembly”
3 Main module “Servicing the Main Module”
4 System controls and indicators “Front Panel Components (Service)” on page 14
5 Processor modules (4 fully populated) or
processor filler modules (slot 1 and slot 2)
“Servicing Processor Modules”
6 Chassis “Servicing the Rear Chassis Subassembly”
7 Rear chassis subassembly “Servicing the Rear Chassis Subassembly”
8 Fan modules (4) “Servicing Fan Modules”
9 PCIe carriers (16) “Servicing PCIe Cards”
10 Rear I/O module “Servicing the Rear I/O Module”
11 Power supplies (4) “Servicing Power Supplies”
