Tools Needed for Service
Preparing for Service 51
Related Information
■
“Removing Power From the Server” on page 53
■
“Tools Needed for Service” on page 51
Tools Needed for Service
You will need the following tools for most service operations:
■
Antistatic wrist strap
■
Antistatic mat
■
No. 2 Phillips screwdriver
■
Mechanical lift (for rear chassis subassembly removal if only one person is present)
Related Information
■
“Component Service Categories” on page 52
■
“Filler Panels and Modules” on page 51
Filler Panels and Modules
Depending on the configuration, the server can include the following types of filler panels and
modules:
■
Hard drive filler panels
■
DIMM filler panels (these are used only to ship new processor modules). You must remove
all of the DIMM filer panels and replace them with DIMMs before installing the new
processor modules. DIMM filler panels are not supported in running processor modules.
■
PCIe card carriers (these function like filler panels when a card is not installed)
■
Processor filler modules (located in slot 1 and slot 2 in a half-populated server)
Caution - To maintain the proper air flow, all filler panels and modules must remain in the
server unless you remove one to install a functioning component at the same time.
Related Information
■
“Safety Information” on page 49
■
“Component Service Categories” on page 52
■
“Server Upgrade Process” on page 59
