Servicing the Storage Backplanes 99
Servicing the Storage Backplanes
The storage backplances are cold-service components that can be replaced after you remove
the main module. For the location of the storage backplanes, see “Main Module Internal
Component Locations” on page 17.
Caution - This procedure requires that you handle components that are sensitive to electrostatic
discharge. This discharge can cause server components to fail.
These topics describe service procedures for the storage backplanes in the server.
Steps Description Links
1. Remove a storage backplane. “Remove a Storage Backplane” on page 99
2. Install a storage backplane. “Install a Storage Backplane” on page 103
3. Verify the installation. “Verify the Storage Backplane” on page 107
Related Information
■
“Identifying Components”
■
“Detecting and Managing Faults”
■
“Preparing for Service”
■
“Component Service Task Reference” on page 23
■
“Returning the Server to Operation”
Remove a Storage Backplane
The storage backplances are cold-service components that can be replaced after you remove the
main module.
Caution - This procedure requires that you handle components that are sensitive to electrostatic
discharge. This discharge can cause server components to fail.
1.
Power off the server, and disconnect the power cords.
