Remove the Service Processor Card
Servicing the Service Processor Card 111
■
target is the remote location where you want to store the configuration information.
For example:
-> dump -destination tftp://129.99.99.99/pathname
2.
Take the necessary ESD precautions.
See “Prevent ESD Damage” on page 57.
3.
Remove the main module from the server.
See “Remove the Main Module” on page 91.
4.
Locate the service processor card on the main module.
See “Main Module Internal Component Locations” on page 17.
5.
Grasp the service processor card by the two grasp points, and lift up to
disengage the service processor card from the connectors on the motherboard.
