Component Service Task Reference
24 SPARC T5-8 Server Service Manual • November 2015
Component Max. NAC Name SDM Name Notes Links
■ Disk drives
(all)
PCIe carriers 16
/SYS/RCSA/PCIEx/ CAR
“Servicing PCIe Cards”
PCIe cards 16
/SYS/RCSA/PCIEx/ CAR/
CARD
/System/ PCI_Devices/Add-
on/Device_x
“Servicing PCIe Cards”
Processor
modules
4
/SYS/PMx /System/ CPU_Modules/
CPU_Module_x
4 for fully
populated
configuration. 2
for half populated
configuration with
2 processor filler
modules.
“Servicing Processor
Modules”
“Server Upgrade
Process” on page 59
Rear I/O module 1
/SYS/RIO
“Servicing the Rear I/O
Module”
Power supplies 4
/SYS/PSx /System/Power/
Power_Supplies/
Power_Supply_x
“Servicing Power Supplies”
Rear chassis
subassembly
1
/SYS/RSCA
“Servicing the Rear Chassis
Subassembly”
SCC PROM 1
/SYS/MB/SCC
“Servicing the System
Configuration PROM”
SP 1
/SP /SP
“Servicing the Service
Processor Card”
Storage
backplanes
2
/SYS/SASB/Px
“Servicing the Storage
Backplanes”
Related Information
■
“Front Panel Components (Service)” on page 14
■
“Rear Panel Components (Service)” on page 15
■
“Chassis Subassembly Components” on page 22
■
“Server Upgrade Process” on page 59
■
