Table 3-1 Description of Callouts for Cabling Oracle Database Appliance X6-2-
HA with a Single Storage Shelf
Callout Number Description
1 Green InfiniBand Cable
• From: Node 0, PCIe slot 1, PORT2
• To: Node 1, PCIe slot 1, PORT2
2 Yellow InfiniBand Cable
• From: Node 0, PCIe slot 1, PORT1
• To: Node 1, PCIe slot 1, PORT1
3 Dark blue SAS cable:
• From: Node 0, PCIe slot 2, SAS0
• To: Storage shelf, top I/O port 0
4 Light blue SAS cable:
• From: Node 0, PCIe slot 3, SAS1
• To: Storage shelf, bottom I/O port 0
5 Dark red SAS cable:
• From: Node 1, PCIe slot 2, SAS1
• To: Storage shelf, top I/O port 1
6 Light red SAS cable:
• From: Node 1, PCIe slot 3, SAS0
• To: Storage shelf, bottom I/O port 1
Cabling Oracle Database Appliance to Connect to Fiber Public
Networks (Optional)
You can configure Oracle Database Appliance X6-2-HA to use 10GbE SFP+ (fiber)
connections for the public network if you ordered the configuration that contains
10GbE SFP+ (fiber) cards instead of InfiniBand cards.
To use fiber connections between Oracle Database Appliance and your public
network, you must cable the interconnect by using the green and yellow copper ports
(onboard ports
net0
and
net1
). The green and yellow Category 6 (
Cat 6
) interconnect
cables for these ports ship with the base system.
The following describes how to connect the ports:
• Plug the green Cat 6 cable into the onboard NET 1 port on each node, as shown
in callout 1 in the figure.
• Plug the yellow Cat 6 cable into the onboard NET 0 port on each node, as shown
in callout 2 in the figure.
Chapter 3
Attaching Supplied Cables for Oracle Database Appliance
3-3
