DP-C405/C305/C265
FEB 2008Ver. 1.1
(5) Lift and place the machine on the Paper Tray,
aligning it with Front and Side covers.
Caution:
1. The machine weights approximately 360.8 lb
(164 kg). To prevent injuries, use the appropriate
number of personnel, and the proper equipment
to lift, or move the machine.
2. The Separate Printer Unit weights approximately
275 lb (125 kg). To prevent injuries, use the
appropriate number of personnel, and the proper
equipment to lift, or move the Printer Unit.
(6) Loosen 3 Screws.
(7) Remove the Lower Rear Cover.
(8) Connect the pre-installed Harness in the
machine to the pre-installed Harness in the
Paper Tray.
To Next Page
