Panasonic MN103S - Page 206

Chapter 8
8-bit Timer
VIII - 16 Control Registers
■ Timer 2 Binary Counter (TM2BC: 0x0000A194) [8-bit Access Register]
■ Timer 3 Binary Counter (TM3BC: 0x0000A195) [8-bit Access Register]
■ Timer 4 Binary Counter (TM4BC: 0x0000A1B0) [8-bit Access Register]
■ Timer 5 Binary Counter (TM5BC: 0x0000A1B1) [8-bit Access Register]
■ Timer 6 Binary Counter (TM6BC: 0x0000A1B4) [8-bit Access Register]
bp 76543210
Flag TM2
BC7
TM2
BC6
TM2
BC5
TM2
BC4
TM2
BC3
TM2
BC2
TM2
BC1
TM2
BC0
At reset 00000000
Access RRRRRRRR
bp 76543210
Flag TM3
BC7
TM3
BC6
TM3
BC5
TM3
BC4
TM3
BC3
TM3
BC2
TM3
BC1
TM3
BC0
At reset 00000000
Access RRRRRRRR
bp 76543210
Flag TM4
BC7
TM4
BC6
TM4
BC5
TM4
BC4
TM4
BC3
TM4
BC2
TM4
BC1
TM4
BC0
At reset 00000000
Access RRRRRRRR
bp 76543210
Flag TM5
BC7
TM5
BC6
TM5
BC5
TM5
BC4
TM5
BC3
TM5
BC2
TM5
BC1
TM5
BC0
At reset 00000000
Access RRRRRRRR
bp 76543210
Flag TM6
BC7
TM6
BC6
TM6
BC5
TM6
BC4
TM6
BC3
TM6
BC2
TM6
BC1
TM6
BC0
At reset 00000000
Access RRRRRRRR
