Panasonic MN103S

Chapter 9
16-bit Timer
IX - 2 Overview
9.1 Overview
This LSI contains 6 general-purpose 16-bit timers (Timer 8, timer 9, timer 10, timer 11, timer 12, and timer 13).
9.1.1 Functions
Table: 9.19. shows the function of each timer.
Table:9.1.1 16-bit Timer Functions
Timer 8 Timer 9 Timer 10 Timer 11 Page
Interrupt cause NTMHIRQ8
NTMAIRQ8
NTMBIRQ8
NTMHIRQ9
NTMAIRQ9
NTMBIRQ9
NTMHIRQ10
NTMAIRQ10
NTMBIRQ10
NTMHIRQ11
NTMAIRQ11
NTMBIRQ11
-
Interval timer O O O O VIII-39
Event count O O O O VIII-43
Up/down count O O O O VIII-48
Timer output O O O O VIII-52
PWM output O O O O VIII-57
Input capture O O O O VIII-63
1-shot output O O O O VIII-66
External trigger activation O O O O VIII-68
A/D conversion start - - - - VIII-72
Count clock source IOCLK
IOCLK/8
IOCLK/64
Timer 2 underflow
TM8BIO pin input
IOCLK
IOCLK/8
IOCLK/64
Timer 3 underflow
TM9BIO pin input
IOCLK
IOCLK/8
Timer 0 underflow
Timer 1 underflow
TM10BI0 pin input
IOCLK
IOCLK/8
Timer 4 underflow
Timer 5 underflow
TM11IO1 pin input
VIII-39
Timer 12 Timer 13 Page
Interrupt cause NTMHIRQ12
NTMAIRQ12
NTMBIRQ12
NTMHIRQ13
NTMAIRQ13
NTMBIRQ13
-
Interval timer O O VIII-39
Event count - - VIII-43
Up/down count O O VIII-48
Timer output - - VIII-52
PWM output - - VIII-57
Input capture - - VIII-63
1-shot output - - VIII-66
External trigger activation PWM0 only PWM1 only VIII-68
A/D conversion start O O VIII-72
Count clock source IOCLK,MCLK
IOCLK/8,MCLK/8
Timer 6 underflow
Timer 7 underflow
IOCLK,MCLK
IOCLK/8,MCLK/8
Timer 6 underflow
Timer 7 underflow
VIII-39
