Chapter 14
A/D Converter
Control Registers XIV - 11
■ A/D2 Conversion Control Register 1 (AN2CTR1: 0x0000A484) [8,16-bit Control Register]
bp 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Flag
----------
AN2
SHC
1
AN2
SHC
0
AN2
NCH
3
AN2
NCH
2
AN2
NCH
1
AN2
NCH
0
At reset0000000000000000
AccessRRRRRRRRRRR/WR/WR/WR/WR/WR/W
bp Flag Description Setting condition
15-6 - - -
5-4
AN2SHC1
AN2SHC0
Sampling/hold cycle mode
00: 1 cycle
01: 2 cycles
10: 4 cycles
11: 6 cycles
3-0
AN2NCH3
AN2NCH2
AN2NCH1
AN2NCH0
Channel number at generation of trigger
B.
0000: ADIN06
0001: ADIN07
0010: ADIN08
0011: ADIN09
0100: ADIN10
0101: ADIN11
0110: ADIN12
0111: ADIN13
1000: ADIN14
1001: ADIN15
1010: Setting prohibited
1011: Setting prohibited
1100: Setting prohibited
1101: Setting prohibited
1110: Setting prohibited
1111: Setting prohibited
