Adjustment
134
3 319 Number of stitches in right seam
= number of stitches C 1 - 255 32
320 Secondary thread tension right seam
(II = on; I = off) I, II I
321 Width of 2
nd
bar = width D (mm) 1.0 - 5.5 3.4
322 Second width of 2
nd
bar = width D1 (mm) 0.0 - 5.5 0.0
323 Length of 2
nd
bar = length D (mm) 1.0 - 6.0 1.2
324 Second length of 2
nd
bar = length D1 (mm) 0.0 - 6.0 0.0
325 Number of stitches in second bar
= number of stitches D 1 - 99 8
326 Distance of second bar to centre of
cutting line = distance D (mm) -2.0 to 2.0 0.0
327 Secondary thread tension of 2
nd
bar
(II = on; I = off) I, II II
4 401 Delay time for raising clamp 0.00 - 1.50 0.10
402 Start delay after lowering clamp 0.00 - 1.50 0.10
403 Cutting time 0.00 - 2.00 0.10
5 501 Soft start stitches 0 - 15 2
502 Soft start speed 500 - 1500 1500
503 Reduced speed 500 - 4200 3500
504 Suppressed stitches needle thread 0 - 15 3
monitor
505 Suppressed stitches bobbin thread 0 - 15 3
monitor
506 Secondary thread tension at sewing start
(stitches) 0 – 3 0
6 601 Move stepping motor work clamp and
needle
Group Parameter Meaning Setting Standard value
