Adjustment
135
6 602 Display inputs
(0123456789ABCDEF)
Meaning of the display:
0 = Error bobbin thread monitor
1 = Error needle thread monitor
2 = Needle in material ( NIS )
3 = Reference needle ( needle centre )
4 = not assigned ( E12 )
5 = not assigned ( E11 )
6 = not assigned ( E10 )
7 = not assigned ( E9 )
8 = not assigned ( E8 )
9 = programmable input 1 ( E7)
A = programmable input 2 ( E6 )
B = Key for knife suppression
B = on sewing head ( E5 )
C = Basic position knife ( E4 )
D = Clamp lowered ( E3 )
E = Basic position cutter ( E2 )
F = Reference clamp ( E1 )
603 Switch outputs
1 = Clamp (O1)
2 = Secondary thread tension (O2)
3 = Knife (O3)
4 = Cutter (O4)
5 = not assigned (O5)
6 = not assigned (O6)
7 = programmable outlet 1 (07)
8 = programmable outlet 2 (08)
(1 = ON; 0 = OFF) 1.0
605 Position of the needle to the workpiece 0 - 127 15
606 Reference point -Needle to work clamp
607 Turn sewing motor in direction of
sewing
608 Carry out cold start RESET
609 Reference point - machine to motor
610 Move to needle positions for hook 1 - 4
adjustment
1 - left seam, right needle entry
2 - right seam, right needle entry
3 - right seam, left needle entry
4 - left seam, left needle entry
612 Adjusting aid for zero position of the 1, 0
sewing motor
(factory presetting with gauge)
Group Parameter Meaning Setting Standard value
