To adjust the rotary feeder deck angle:
1. Turn the middle two blue angle adjustment knobs clockwise or counterclockwise to adjust the
angle up or down.
Item Description
1 Angle Adjustment Knob
2 Angle Adjustment Marks
Adjust the Rotary Feeder Deck Angle
2. Use the angle adjustment marks on the side frame for reference.
Operator Adjustments
Pitney Bowes Epic v3.1 (ZVE0) Operator Guide May, 2018 Page 127 of 328
