Removing Material Jams in the Friction Feeder
There are three areas in the friction feeder where material jams may occur:
l Feeder deck
l Separator bridge
l Transport
Feeder Deck
1. Lower the front feeder cover where the indicator light is flashing.
2. Raise the feeder by pushing up and away on the side guide. The feeder pivots, allowing access to
the bottom of feeder and chassis deck area. DO NOT press on LED lens cover when lifitng feeder.
Feeder Lifted; Material Access Area
3. Remove the jammed material.
Error Recovery
Pitney Bowes Epic v3.1 (ZVE0) Operator Guide May, 2018 Page 221 of 328
