Rotary Feeder Maintenance
Perform these maintenance activities daily.
Note:
All routine maintenance must be performed with the system logged off.
Required Tools
l Shop air
Cleaning and Replacing Rotary Feeder Suction Cups
If a suction cup is torn or worn, it will need to be replaced.
1. Remove material from the hopper.
2. Remove, inspect, and replace suction cups if damaged.
3. Use low pressure shop air to blow dust and debris out of the paper path and remove any toner
buildup on the deck.
4. If you need to replace the suction cup, pull it off the cup holder.
5. Remove the old suction cup from the ring.
6. Place the new suction cup on the ring.
7. Return the cup into the cup holder.
Maintenance
Pitney Bowes Epic v3.1 (ZVE0) Operator Guide May, 2018 Page 267 of 328
