Adjusting the Booklet Feeder Double Detect Feature
The double detect feature detects when more than one piece of material is fed from the insert feeder. If
the double detect feature is not working properly, try adjusting it. For example, if you are running material
that runs about 50% thinner or thicker than the material from the previous job, you should adjust the
booklet feeder double detect.
Adjusting Double Detect
Note:
l When you check the double detect it's important to set the double detect for the insert material for
the job.
l Also, use the same location on the insert that the double detect roller will make contact with. For
example, don't set the double detect on the thickest portion of the insert if that section will not be
under the double detect roller once the feeder is properly set up.
1. Loosen both mounting screws using the setup tool, and slide the double detect bracket to its
highest position.
Operator Adjustments
Pitney Bowes Epic v3.1 (ZVE0) Operator Guide May, 2018 Page 155 of 328
