Using the Wedge Accessory on the Rotary Feeder
The wedge is an optional accessory that can be used to help support certain types of material as it is fed
into the inserter from the rotary feeder. The wedge lifts the trail edge of the material to give the material
more support.
Refer to the table included here to see if the material you are running requires the use of the wedge.
Material Type Wedge
(Single Sheet (#10, A4, half-fold non-glossy, half-fold glossy) optional
Folded, perfume optional
BRE optional
Booklet (thick .125" max) yes
Booklet (thin) yes
Installing the Wedge on the Rotary Feeder
1. Lift the wedge off the back wall of the feeder.
Wedge
Operator Adjustments
Pitney Bowes Epic v3.1 (ZVE0) Operator Guide May, 2018 Page 131 of 328
