Auto Adjustments - Engine and Chassis
The most common adjustments in the Epic v3.1 inserter are adjusted automatically, based on mode
settings and entries operators make in DC. These default adjustments settings will be sufficient for most
standard material, but occasionally minor adjustments are needed.
Note:
Areas of the Epic v3.1 system that auto adjust are identified in the Job Changeover Guidelines section.
Auto Adjust Engine Settings
Engine Settings
The entrance nip rollers and the pocket stops adjust to the length of the envelope in the mode. Both the
pocket width offset and pocket center offset settings can be manually adjusted in the Engine Setup
screen.
Horns Settings
The horns adjust to be centered on the envelope. The width of the horns uses the widest measurement
of either the envelope or material on the chassis. The horn width offset setting can be manually
adjusted in the Engine Setup screen.
Insert Blower Offset
The amount of vacuum on the vacuum deck can be increased or decreased. It is not normally necessary
to change this setting, but it can be manually adjusted in the Engine Setup screen if needed.
Backwall Settings
The backwall adjusts based on the depth of the envelope, to set the crease line of the envelope
consistent with the sealer brush (which stays in a fixed position). The backwall offset position setting
can be manually adjusted in the Engine Setup screen.
Job Changeover Guidelines
Pitney Bowes Epic v3.1 (ZVE0) Operator Guide May, 2018 Page 185 of 328
