Adjusting the Suction Cups in the Engine
The suction cups in the engine open up the throat of the envelope for insertion. They can be adjusted to
accommodate different envelope throat sizes.
1. Lift the engine cover.
2. Lift the upper engine to access the vacuum deck.
3. Open the envelope and fold the flap inside, so the throat of the envelope is showing.
4. Align the top of the envelope (flap crease line) with the deck lines shown here. (This is where the
envelope is staged. All adjustments should be made from this position.)
Align Envelope
Operator Adjustments
Pitney Bowes Epic v3.1 (ZVE0) Operator Guide May, 2018 Page 56 of 328
