Envelope Specifications
Envelopes whose characteristics fall outside of these construction guidelines must be evaluated by
testing of customer samples.
Primary Envelope Requirements
The Epic system processes the following types of envelopes:
l Executive envelopes (to achieve maximum productivity, truncated flap is recommended)
l Diagonal cut envelopes
l Side seam envelopes
l McIntyre side seam envelopes (if examined and approved by Pitney Bowes)
Envelope Guidelines
l All seams should be securely bonded to the bottom flap without exhibiting any curl or ripple
between the flaps.
l Envelope curl or twist should not exceed .25" (6.4 mm) when the envelope is placed on a flat
surface.
l The envelope throat should be a maximum of .25" (6.4 mm) below the crease line at .75" (19 mm)
from the side edges.
Envelope
Measurements
Minimum Maximum Maximum Epic Flats
Width* 7" (178 mm) 11.50" (292 mm) 13.9" (353 mm)
Length** 3.88" (98 mm) 6.38" (162 mm) 10" (259 mm)
Weight 20 lb bond (75 gsm) 28 lb bond (105 gsm) 28 lb bond (105 gsm)
End Clearance See End Clearance 1.25" (32 mm) 1.25" (32 mm)
Bottom of Flap to crease line 1.25" (32 mm) 1.75" (44 mm) standard
2.50" (64 mm) custom
1.75" (44 mm) standard
2.50" (64 mm) custom
* Width is defined as the dimension parallel to the address direction
* * Length is defined as the dimension perpendicular to the address direction
Specifications
Pitney Bowes Epic v3.1 (ZVE0) Operator Guide May, 2018 Page 281 of 328
