Horns
Three sets of horns are provided.
Maximum Collation
Thickness
Minimum End
Clearance, Total
Minimum Envelope
Width (mm)
Left Horn Right
Horn
mm inches mm inches mm inches
Narrow
Envelopes
ZY56464 ZY56465 3 0.12 10 0.37 177.6 6.99
Standard
Envelopes
ZY56452 ZY56451 9 0.35 15 0.58 194.8 7.67
Thick
Envelopes
ZV51233 ZV51233 12.7 0.50 21 0.83 221.2 8.71
ZVE0 Engine Horn Matrix
End Clearance
End clearance is the difference between the dimension of the largest insert and the length of the
envelope when measured with all inserts in the envelope.
A .75" (19.1 mm) end clearance is recommended to achieve maximum throughput for all categories.
Experience has shown that end clearance requirements increase with the height of the collation and / or
with the number of pages comprising the input document.
Specifications
