Setting Backup Feeders (Backup Feed Mode)
You can select a feeder to back up a primary feeder when it runs low on material during a job run. When
this mode is selected the Feeder object has green stripes.
About Backup Feeder Locations
The backup feeder must be downstream (the direction the paper travels) of the primary feeder. In this
example the following feeders are assigned:
l Feeder #3 is the primary feeder and set in backup mode
l Feeder #2 (downstream) is set to back up Feeder #3
l When Feeder #3 runs low on material, Feeder #2 takes over until Feeder #3 is reloaded and in a
ready state
Item Description
1 Feeder #3
2 Backup Feeder #2
3 Backup Feeder (green stripes)
Backup Feeder Locations
Operator Adjustments
Pitney Bowes Epic v3.1 (ZVE0) Operator Guide May, 2018 Page 171 of 328
