Adjusting the O-ring Belt Height
If the height is incorrect, you can adjust the height of the buffer upper O-ring belts. In most cases, once
they are set, these belts do not need to be adjusted.
1. Locate the adjustment screw.
2. Using the 3/16" operator setup tool, turn the screw as needed to raise or lower to achieve correct
height adjustment.
Operator Adjustments
Pitney Bowes Epic v3.1 (ZVE0) Operator Guide May, 2018 Page 179 of 328
