4. Lower the paddle back to the belt between the two mailpieces and then slide that stack of mail to
the right of the paddle into the mail tray.
Item Description
1 Paddle
2 Mail to be moved to mail tray
Remove Mail
On Edge Stacker Paddle and Switch
The On Edge Stacker signals the operator when the stacker belt is about three quarters full with a
message on the bottom of the main DC screen in the alarm message box.. When the paddle reaches the
switch located on the stacker, the machine will come to a controlled stop and indicate the stacker is full by
displaying a message on the screen.
l The machine will not start while the paddle is pressing on the switch.
l This feature works only when the paddle is in the down position and the inserter is running.
Running the System
