Epic Throughput
Epic Epic Flats
#10 - DL application up to 21K up to 21K
6 x 9 application up to 18K up to 18K
9 x 12 - C4 application* up to 14K**
10 x 13 - B4 application* up to 14K**
* requires flat key ZX29
** the 14K flat speed can be met for collations up to 1 mm or 10 sheets thick. Past that speed the
maximum speed may have to be reduced to maintain seal and stack quality. The seal quality is highly
material dependent. If further characterization is needed, sample material, application details, and detail
on the MOS configuration will have to be provided to the team in Danbury.
Note:
The "Epic Throughput" table (included here) approximates the maximum system throughput based on
a mathematical model of the Epic modules. Lower throughput can be caused by failure to follow the
guidelines outlined in product specifications and/or poor material quality.
Specifications
Pitney Bowes Epic v3.1 (ZVE0) Operator Guide May, 2018 Page 277 of 328
