Physical Characteristics
The physical characteristics of the Epic system:
l Length (along chassis): 88" (226 cm)
l Width (along output): 101" (257 cm)
l Height: 44" (112 cm)
l Heat Dissipation: 2000 watts (6824 BTU/hr)
l Air requirements: 6.3 SCFM @ 70 PSI
l Total Weight: 1790 lbs (812 kg)
o
Engine = 1000 lbs
o
Sealer / VBin = 455 lbs
o
Envelope Feeder = 335 lbs
Air Consumption
Worse case air consumption for a ZVE0, 21-station chassis, 8-stage TNT buffer is 6.5 SCFM.
System Air Consumption Case #1 Case #2
#10@21K (SCFM) subset flats at 7.2K
(SCFM)
Engine 6.44 2.98
21-station chassis 0.10 0.292
8-stage TNT buffer 0.001 0.159
Engine, chassis, buffer total consumption 6.45 3.43
Case #1: 21K, #10, deck nips operate 1% of time for stop conditions. Subset stops and jogger inactive.
Case #2: Flats mode, two subsets of five pages each. Chassis speed of 7.2K, jogger activates 2x per
collation. Subset stops activate 1x per collation. All deck nips go up and down 1x per cycle.
