Material Specifications
Envelope Specifications Minimum Maximum
Length 6.5" (165 mm) see note 2 11.5" (292.1mm)
Width 3.88" (98 mm) 6.5" (165 mm)
Basis Weight 20 lb (75 gsm) 28 lb (105 gsm)
Range of Thickness 25.0" (635 mm)
Notes
l (1) The On Edge Stacker will not process stepped mail applications, such as CDs, DDA check
applications, license plates or credit cards
l (2) Envelopes with external side seams require the External Side Seam kit
Options
The On Edge Stacker can be configured with these optional kits:
Kit Part #
Offset Kit Y49B
Side Seam Kit Y490011
Specifications
Pitney Bowes Epic v3.1 (ZVE0) Operator Guide May, 2018 Page 319 of 328
