7. Slide the suction cup arm to position the suction cup approximately 1/8-inch (3 mm) from the
envelope throat. (Do this for all three suction cups.)
Item Description
1 Envelope Flap
2 Envelope Throat
3 Suction Cups
4 1/8-inch (3 mm) space
Position Suction Cups - 1/8-inch (3 mm) from throat
8. Tighten the suction cup lockdown screws.
9. Remove the envelope.
10. Lower the upper engine.
11. Close the cover.
Operator Adjustments
Pitney Bowes Epic v3.1 (ZVE0) Operator Guide May, 2018 Page 59 of 328
