Remove or Add Vertical Stacker Side Guide
To remove or add a vertical stacker side guide:
1. Loosen both thumb screws that hold the guide in place.
2. Grasp the side guide and slide it to the left of the cross bars.
3. Lift the right side and remove the guide from the module.
Adjust a Vertical Stacker Side Guide
To adjust the position of a vertical stacker side guide:
1. Loosen both thumb screws and slide the guide on the bars to the desired position.
2. Tighten the thumb screws.
Note:
When running flats, remove the guides from all vertical stackers before the flats conveyor stacker.
Operator Adjustments
Pitney Bowes Epic v3.1 (ZVE0) Operator Guide May, 2018 Page 83 of 328
