Removing the Flat Stacker
1. Remove the three electrical connections on the non-operator side of the vertical stacker:
a. Unscrew the connector at the base.
b. Squeeze the top and bottom tab while gently pulling the connector free.
c. Pull the blue connector off the base.
Item Description
A Connector
B Tab
C Pull connector off
Remove Electrical Connections
Operator Adjustments
Pitney Bowes Epic v3.1 (ZVE0) Operator Guide May, 2018 Page 85 of 328
