Planet GS-4210-16T2S - Page 161

User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
161
Figure 4-6-7: STP Port Status Page Screenshot
The page includes the following fields:
Object Description
• Port
The switch port number of the logical STP port.
• Admin Enable
Display the current STP port mode status.
• External Cost
Display the current external cost.
• Edge Port
Display the current edge port status.
