User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
187
Figure 4-7-18: Static Router Table Page Screenshot
The page includes the following fields:
Object Description
• VLAN ID
Display the current VLAN ID.
• Port Mask
Display the current port mask.
Figure 4-7-19: Forbidden Router Table Page Screenshot
The page includes the following fields:
Object Description
• VLAN ID
Display the current VLAN ID.
• Port Mask
Display the current port mask.
