User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
193
The page includes the following fields:
Object Description
• MLD Snooping Status
Display the current MLD snooping status.
• MLD Snooping Version
Display the current MLD snooping version.
• MLD Snooping V2 Report
Suppression
Display the current MLD snooping V2 report suppression.
Figure 4-7-24: MLD Snooping Table Page Screenshot
The page includes the following fields:
Object Description
• Entry No.
Display the current entry number.
• VLAN ID
Display the current VLAN ID.
• MLD Snooping Operation
Status
Display the current MLD snooping operation status.
• Router Ports Auto Learn
Display the current router ports auto learning.
• Query Robustness
Display the current query robustness.
• Query Interval (sec.)
Display the current query interval.
• Query Max Response
Interval (sec.)
Display the current query max response interval.
• Last Member Query count
Display the current last member query count.
• Last Member Query
Interval (sec)
Display the current last member query interval.
• Immediate Leave
Display the current immediate leave.
• Modify
Click to edit parameter.

Planet GS-4210-16T2S Specifications

General

Switch type	Managed
Switch layer	L2/L4
Quality of Service (QoS) support	Yes
Console port	RJ-45
SFP module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
10G support	No
Number of VLANs	4094
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Authentication	Port-based authentication
Security algorithms	802.1x RADIUS, HTTPS, SSH, SSL/TLS
Stackable	-
Form factor	1U
Certification	FCC, CE
Product color	Blue
Housing material	Metal
Throughput	26.7 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Supported network protocols	IPv4 / IPv6
Input current	0.8 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	10.4 W
Heat dissipation	35 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Fiber ethernet cabling technology	1000BASE-X
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	207 mm
Width	445 mm
Height	45 mm
Weight	2000 g
