User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
297
The page includes the following fields:
Object Description
• Server Definition
Set the server definition.
• Server IP
Address of the TACACS+ server IP/name.
• Server Port
Network (TCP) port of TACACS+ server used for authentication messages.
(Range: 0-65535; Default: 49)
• Server Key
The key- shared between the TACACS+ Authentication Server and the switch.
• Server Timeout
The number of seconds the switch waits for a reply from the server before it
resends the request. (Range: 1-30 seconds)
• Server Priority
Set the server priority. (Range: 0-65535)
Button
: Click to add TACACS+ Server setting.
Figure 4-9-58: Login Authentication List Page Screenshot
The page includes the following fields:
Object Description
• IP Address
Display the current IP address.
• Port
Display the current port.
• Key
Display the current key.
• Timeout
Display the current timeout.
• Priority
Display the current priority
• Modify
Click
to edit login authentication list parameter.
Click to delete login authentication list entry.

Planet GS-4210-16T2S Specifications

General

Switch type	Managed
Switch layer	L2/L4
Quality of Service (QoS) support	Yes
Console port	RJ-45
SFP module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
10G support	No
Number of VLANs	4094
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Authentication	Port-based authentication
Security algorithms	802.1x RADIUS, HTTPS, SSH, SSL/TLS
Stackable	-
Form factor	1U
Certification	FCC, CE
Product color	Blue
Housing material	Metal
Throughput	26.7 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Supported network protocols	IPv4 / IPv6
Input current	0.8 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	10.4 W
Heat dissipation	35 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Fiber ethernet cabling technology	1000BASE-X
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	207 mm
Width	445 mm
Height	45 mm
Weight	2000 g
