User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
3 times before it is considered to be dead.
• Retries
Timeout is the number of seconds, in the range 1 to 10, to wait for a reply from a
RADIUS server before retransmitting the request.
• Server Priority
Set the server priority. (Range: 0-65535)
• Dead Time
The Dead Time, which can be set to a number between 0 and 3600 seconds, is
the period during which the switch will not send new requests to a server that has
failed to respond to a previous request. This will stop the switch from continually
trying to contact a server that it has already determined as dead.
Setting the Dead Time to a value greater than 0 (zero) will enable this feature, but
only if more than one server has been configured. (Range: 0-2000)
• Usage Type
Set the usage type. The following modes are available:
Login
802.1X
All
Button
: Click to add Radius server setting.
Figure 4-9-61: Login Authentication List Page Screenshot
The page includes the following fields:
Object Description
• IP Address
Display the current IP address.
• Auth Port
Display the current auth port.
• Acct Port
Display the current acct port.
• Key
Display the current key.
• Timeout
Display the current timeout.
• Retries
Display the current retries times.
• Priority
Display the current priority.
• Dead Time
Display the current dead time
• Usage Type
Display the current usage type.
• Modufy
Click
to edit login authentication list parameter.
Click to delete login authentication list entry.
